Administração
e Optimização
de Bases de
Dados
Administração e Optimização
de Bases de Dados
Expression Equivalence Rules
Departamento de Engenharia Informática
Instituto Superior Técnico
2nd Semester
2009/2010
Slides baseados nos slides oficiais do livro
“Database System Concepts”
c
Silberschatz,
Korth and Sudarshan.
Equivalence Rules I
Administração
e Optimização
de Bases de
Dados
1) Conjunctive selection operations can be deconstructed into
a sequence of individual selections
σθ1 ∧θ2 (E ) = σθ1 (σθ2 (E ))
2) Selection operations are commutative
σθ1 (σθ2 (E )) = σθ2 (σθ1 (E ))
3) Only the last in a sequence of projection operations is
needed, the others can be omitted
πL1 (πL2 (. . . (πLn (E )) . . . )) = πL1 (E )
Equivalence Rules II
Administração
e Optimização
de Bases de
Dados
4) Selections can be combined with Cartesian products and
theta joins
σθ (E1 × E2 ) = E1 ⊲⊳θ E2
σθ1 (E1 ⊲⊳θ2 E2 ) = E1 ⊲⊳θ1 ∧θ2 E2
5) Theta-join operations and natural joins are commutative
E1 ⊲⊳θ E2 = E2 ⊲⊳θ E1
Equivalence Rules III
Administração
e Optimização
de Bases de
Dados
6) Join operations are associative
(a) Natural join operations are associative
(E1 ⊲⊳ E2 ) ⊲⊳ E3 = E1 ⊲⊳ (E2 ⊲⊳ E3 )
(b) Theta joins are associative in the following manner
(E1 ⊲⊳θ1 E2 ) ⊲⊳θ2 ∧θ3 E3 = E1 ⊲⊳θ1 ∧θ3 (E2 ⊲⊳θ2 E3 )
where θ2 involves attributes from only E2 and E3
Equivalence Rules IV
Administração
e Optimização
de Bases de
Dados
Example
(customer ⊲⊳c.c
name=d.c name
depositor )
⊲⊳d.a number =a.a number ∧balance>1000 account
=
customer ⊲⊳c.c
name=d.c name∧balance>1000
(depositor ⊲⊳d.a number =a.a number account)
Equivalence Rules V
Administração
e Optimização
de Bases de
Dados
7) The selection operation distributes over the theta join
operation under the following two conditions:
(a) When all the attributes in θ0 involve only the attributes of
one of the expressions (E1 ) being joined
σθ0 (E1 ⊲⊳θ E2 ) = (σθ0 (E1 )) ⊲⊳θ E2
(b) When θ1 involves only the attributes of E1 and θ2 involves
only the attributes of E2
σθ1 ∧θ2 (E1 ⊲⊳θ E2 ) = (σθ1 (E1 )) ⊲⊳θ (σθ2 (E2 ))
Equivalence Rules VI
Administração
e Optimização
de Bases de
Dados
Example
σc
name=Smith∧balance>1000 (depositor
⊲⊳ account)
=
σc
name=Smith (depositor )
⊲⊳ σbalance>1000 (account)
Equivalence Rules VII
Administração
e Optimização
de Bases de
Dados
8) The projections operation distributes over the theta join
operation as follows:
(a) Let L1 and L2 be attributes from E1 and E2 . If the join
involves only attributes in L1 ∪ L2
πL1 ∪L2 (E1 ⊲⊳θ E2 ) = πL1 (E1 ) ⊲⊳θ πL2 (E2 )
(b) Let L3 be attributes of E1 that are involved in the join
condition, but are not in L1 ∪ L2 , and let L4 be attributes of E2
that are involved in the join condition, but are not in L1 ∪ L2
πL1 ∪L2 (E1 ⊲⊳θ E2 ) = πL1 ∪L2 ((πL1 ∪L3 (E1 )) ⊲⊳θ (πL2 ∪L4 (E2 )))
Equivalence Rules VIII
Administração
e Optimização
de Bases de
Dados
Example
πb name,c
name (account
⊲⊳a.a number =d.a
number
depositor )
=
πb
name,c name ((πb name,a number (E1 ))
⊲⊳a.a number =d.a
(πc
number
name,a number (E2 )))
Equivalence Rules IX
Administração
e Optimização
de Bases de
Dados
9) The set operations union and intersection are commutative
E1 ∪ E2 = E2 ∪ E1
E1 ∩ E2 = E2 ∩ E1
10) Set union and intersection are associative
(E1 ∪ E2 ) ∪ E3 = E1 ∪ (E2 ∪ E3 )
(E1 ∩ E2 ) ∩ E3 = E1 ∩ (E2 ∩ E3 )
Equivalence Rules X
Administração
e Optimização
de Bases de
Dados
11) The selection operation distributes over ∪, ∩ and −
σθ (E1 − E2 ) = σθ (E1 ) − σθ (E2 )
and similarly for ∪ and ∩. Also
σθ (E1 − E2 ) = σθ (E1 ) − E2
and similarly for ∪ and ∩
12) The projection operation distributes over union
πL (E1 ∪ E2 ) = πL (E1 ) ∪ πL (E2 )
Other rules also exist for outer joins, aggregations, ...
Transformation Example
Administração
e Optimização
de Bases de
Dados
Query: Find the names of all customers who have an
account at some branch located in Brooklyn
πcustomer
name (σbranch city =Brooklyn (branch
⊲⊳
(account ⊲⊳ depositor )))
Transformation using rule 7(a)
πcustomer
name ((σbranch city =Brooklyn (branch))
⊲⊳
(account ⊲⊳ depositor ))
Performing the selection as early as possible reduces the
size of the relation to be joined
Multiple Transformations
Administração
e Optimização
de Bases de
Dados
Query: Find the names of all customers with an account
at a Brooklyn branch whose account balance is over $1000
πcustomer
name ((σbranch city=Brooklyn∧balance>1000
(branch ⊲⊳ (account ⊲⊳ depositor )))
Transformation using join associatively (rule 6(a)):
πcustomer
name ((σbranch city=Brooklyn∧balance>1000
(branch ⊲⊳ account) ⊲⊳ depositor ))
Second form provides an opportunity to apply the
“perform selections early” rule, resulting in the expression
πcustomer
name ((σbranch city=Brooklyn (branch)
⊲⊳
σbalance>1000 (account)) ⊲⊳ depositor )
Multiple Transformations (cont.)
Administração
e Optimização
de Bases de
Dados
πcustomer
πcustomer
name
σbranch city = Brooklyn ∧
name
⊲⊳
balance > 1000
⊲⊳
branch
account
⊲⊳
σbranch
depositor
⊲⊳
depositor
city =Brooklyn
σbalance>1000
branch
account
Projection Operation Example
Administração
e Optimização
de Bases de
Dados
Consider the query
πcustomer
name ((σbranch city =Brooklyn (branch)
⊲⊳ account)
⊲⊳ depositor )
When we compute σbranch city =Brooklyn (branch) ⊲⊳ account,
we get a relation whose schema is
(branch name, branch city , assets, account number , balance)
Push projections using equivalence rules 8(a) and 8(b)
eliminate unneeded attributes from intermediate results
πcustomer
name (πaccount number
(σbranch
city =Brooklyn (branch)
⊲⊳ account)
⊲⊳ depositor )
Join Ordering Example
Administração
e Optimização
de Bases de
Dados
Consider the expression
πcustomer
name ((σbranch city =Brooklyn (branch))
⊲⊳
(account ⊲⊳ depositor ))
Could compute (account ⊲⊳ depositor ) first, and join result
with σbranch city =Brooklyn (branch)
However, (account ⊲⊳ depositor ) is likely to be a large
relation...
... and only a small fraction of the bank’s customers are
likely to have accounts in branches located in Brooklyn
Thus, it is better to compute first
σbranch
city =Brooklyn (branch)
⊲⊳ account
Administração
e Optimização
de Bases de
Dados
The End
