ST2310HI
®
HIGH VOLTAGE FAST-SWITCHING
NPN POWER TRANSISTOR
■
■
■
■
■
■
NEW SERIES, ENHANCED PERFORMANCE
FULLY INSULATED PACKAGE (U.L.
COMPLIANT) FOR EASY MOUNTING
HIGH VOLTAGE CAPABILITY ( > 1500 V)
HIGH SWITCHING SPEED
TIGTHER hfe CONTROL
IMPROVED RUGGEDNESS
3
APPLICATIONS:
HORIZONTAL DEFLECTION FOR
MONITORS 15" AND HIGH END TVS
2
■
DESCRIPTION
The device is manufactured using Diffused
Collector technology for more stable operation Vs
base drive circuit variations resulting in very low
worst case dissipation.
1
ISOWATT218
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS
Symbol
V CES
V CEO
V EBO
IC
I CM
IB
P tot
V isol
T stg
Tj
Parameter
Collector-Emitter Voltage (V BE = 0)
Collector-Emitter Voltage (I B = 0)
Emitter-Base Voltage (I C = 0)
Collector Current
Collector Peak Current (t p < 5 ms)
Base Current
Total Dissipation at T C = 25 o C
Insulation Withstand Voltage (RMS) from All
Three Leads to External Heatsink
Storage Temperature
Max. Operating Junction Temperature
December 2002
Value
1500
600
7
12
25
7
55
2500
-65 to 150
150
Unit
V
V
V
A
A
A
W
V
o
o
C
C
1/6
ST2310HI
THERMAL DATA
R thj-case
Thermal Resistance Junction-case
Max
o
2.3
C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified)
Symbol
Parameter
Test Conditions
I CES
Collector Cut-off
Current (V BE = 0)
V CE = 1500 V
V CE = 1500 V
I EBO
Emitter Cut-off Current
(I C = 0)
V EB = 7 V
V CEO(sus) ∗ Collector-Emitter
Sustaining Voltage
(I B = 0)
Min.
Typ.
T J = 125 o C
I C = 100 mA
L = 25 mH
Max.
Unit
1
2
mA
mA
1
mA
600
V
V CE(sat) ∗
Collector-Emitter
Saturation Voltage
IC = 7 A
I B = 1.75 A
3
V
V BE(sat) ∗
Base-Emitter
Saturation Voltage
IC = 7 A
I B = 1.75 A
1.1
V
DC Current Gain
IC = 1 A
IC = 7 A
IC = 7 A
V CE = 5 V
V CE = 1 V
V CE = 5 V
IC = 6 A
I B(on) = 1 A
L BB(off) = 1.3 µH
f h = 64 KHz
V BE(off) = -2.5 V
(see figure 1)
h FE ∗
ts
tf
INDUCTIVE LOAD
Storage Time
Fall Time
∗ Pulsed: Pulse duration = 300 µs, duty cycle 1.5 %
Safe Operating Area
2/6
Thermal Impedance
25
5.4
9.5
6.5
2.3
0.16
3
0.35
µs
µs
ST2310HI
Derating Curve
Output Characteristics
Collector Emitter Saturation Voltage
Base Emitter Saturation Voltage
DC Current Gain
DC Current Gain
3/6
ST2310HI
Power Losses
Reverse Biased SOA
Figure 1: Inductive Load Switching Test Circuit.
4/6
Switching Time Inductive Load
ST2310HI
ISOWATT218 NARROW LEADS MECHANICAL DATA
DIM.
A
C
D
D1
E
F
F2
F3
F5
G
H
L
L1
L2
L3
L4
L5
L6
N
R
DIA
MIN.
5.35
3.30
2.90
1.88
0.75
0.75
1.50
1.90
mm
TYP.
10.80
15.80
MAX.
5.65
3.80
3.10
2.08
0.95
0.95
1.70
2.10
1.10
11.20
16.20
MIN.
0.211
0.130
0.114
0.074
0.030
0.030
0.059
0.075
21.20
19.90
23.60
42.50
5.25
20.75
2.3
0.819
0.752
0.898
1.594
0.191
0.797
0.083
3.7
0.138
0.425
0.622
9
20.80
19.10
22.80
40.50
4.85
20.25
2.1
MAX.
0.222
0.150
0.122
0.082
0.037
0.037
0.067
0.083
0.043
0.441
0.638
0.354
4.6
3.5
inch
TYP.
0.835
0.783
0.929
1.673
0.207
0.817
0.091
0.181
- Weight : 4.9 g (typ.)
- Maximum Torque (applied to mounting flange) Recommended: 0.8 Nm; Maximum: 1 Nm
- The side of the dissipator must be flat within 80 µm
0.146
P025C/B
5/6
ST2310HI
